Terminal 1 + socket 63

Wire resistance: max. 1.5 ohm

Fig. 5: Identifying Throttle Position And Accelerator Position Sensor Harness Connector
Terminals (121-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

z

Also check wires for short circuit to each other, to vehicle Ground (GND) and to B+.

Specified value: INFINITY ohm

If no malfunction is detected in the wiring and if the voltage supply was OK:

z

Replace accelerator pedal position sensor. See item 4 .

z

Erase DTC memory of control module for Diesel - Direct fuel injection system. See DIAGNOSTIC
MODE 4: RESET/ERASE DIAGNOSTIC DATA .

z

Generate readiness code. See READINESS CODE, GENERATING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle



1998-2004 ENGINE

Fuel System - New Beetle, 1.8L (APH, AWV & AWP)

FUEL SUPPLY SYSTEM COMPONENTS, REMOVING AND INSTALLING

z

Observe safety precautions. See SAFETY PRECAUTIONS WHEN WORKING ON FUEL SUPPLY
SYSTEM .

z

Observe rules for cleanliness. See RULES OF CLEANLINESS .

Removing and installing fuel tank with its attachments and fuel filter. See FUEL TANK WITH
ATTACHMENTS AND FUEL FILTER, REMOVING AND INSTALLING .

Observe crash fuel shut-off. See CRASH FUEL SHUT-OFF .

Electronic Engine Power Control (EPC) system, checking. See ELECTRONIC ENGINE POWER
CONTROL (EPC) SYSTEM COMPONENTS, CHECKING .

Servicing parts of the Evaporative Emission (EVAP) system. See EVAPORATIVE EMISSION (EVAP)
SYSTEM COMPONENTS, SERVICING .

FUEL TANK WITH ATTACHMENTS AND FUEL FILTER, REMOVING AND INSTALLING

1. Sealing cap

z

Secured with strap from MY 2000

2. Seal

z

Replace if damaged

3. Securing screw

4. Tank flap unit

z

With rubber cup

5. Vent pipe

z

Black

z

Check securely seated

NOTE:

z

Hose connections are secured with either spring-type or clamp-type clips.

z

Always replace clamp-type clips with screw-type clips.

z

Fuel hoses in engine compartment must only be secured with spring-type
clips. The use of clamp or screw-type clips is not permissible.

z

Assembly tool VAS 5024 or hose clip pliers VAG 1921 are recommended
for installing spring-type clips.

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



z

Clipped onto top of fuel tank

6. Ground connection

z

Check securely seated

7. Vent pipe

z

White

z

Check securely seated

z

Checking. See Checking Change-Over Valve

8. Gravity/overflow valve

z

To remove valve unclip upward out of support

z

Check valve for throughflow:

„

Valve vertical: open

„

Valve tilted 45°: closed

9. O-ring

z

Replace if damaged

10. Change-over valve

z

To remove valve, unclip sideways out of support.

z

Before installing remove sealing cap item 1.

z

Checking. See Checking Change-Over Valve

11. Vent pipe

z

Black

z

Check securely seated

z

To EVAP canister. See EVAPORATIVE EMISSION (EVAP) SYSTEM, OVERVIEW , Pos.6

z

To remove from flange, press release button on connecting piece.

12. Pressure retaining valve

z

For fuel tank breathing

z

Checking. See Checking Pressure Retaining Valve

13. Vent pipe

z

Black

z

Check securely seated

z

Secure with spring-type clips

14. Fuel tank

z

Support with engine and transmission jack VAG 1383 A when removing

z

Removing and installing. See FUEL TANK, REMOVING AND INSTALLING

15. Clamping washer

16. Heat shield

z

For fuel tank

17. 25 N.m



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



18. Lock nut, 2 N.m

19. Fuel tank cover

20. Securing strap

z

Note differing length

z

Installation position: Fixing point (holes) point in direction of travel

21. Supply pipe

z

Black

z

Check securely seated

z

Press disengaging tabs at connecting piece to pull off fuel filter

z

To fuel supply hose on fuel rail:

See Fuel Rail With Injectors, Disassembling And Assembling .

22. Fuel filter

z

Installation position: -arrow- points in throughflow direction

23. Screw-type clip

24. Vent pipe

z

White

z

Check securely seated

z

Clipped onto side of fuel tank

z

To EVAP Canister Purge Regulator Valve -N80-

25. Sealing ring

z

Replace if damaged

z

When installing, insert seal "dry" into fuel tank opening

z

Only coat with fuel when installing fuel delivery unit flange

26. Fuel delivery unit

z

Note installation position on fuel tank. See Installation Position Of Fuel Delivery Unit Flange

z

Removing and installing. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING

z

Removing and installing fuel gauge sensor. See FUEL GAUGE SENSOR, REMOVING AND
INSTALLING

z

Checking fuel pump. See FUEL PUMP, CHECKING

z

Clean strainer if soiled

27. Union nut, 75 N.m

z

Remove and install with spanner 3217

28. Supply pipe

z

Black

z

Check securely seated

z

Clipped onto side of fuel tank
