Fig. 6: Identifying VAG 1332 Torque Wrench (40-200 N.m) z 3217 Ring nut wrench Fig. 7: Identifying 3217 Ring Nut Wrench Removing z Note safety precautions before starting work. See SAFETY PRECAUTIONS WHEN WORKING ON z Check whether a coded radio is installed. If so, obtain anti-theft coding. z With ignition switched off disconnect battery Ground strap. z Remove cover under bench seat. z Pull 4-pin connector and supply and return pipes off flange. z Remove union nut with 3217 wrench. WARNING: Fuel supply hoses are under pressure! Before removing from hose
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
|
