Volkswagen New Beetle. Manual - part 1411





Fig. 173: Scan Tool Display - Throttle Position Sensor, From MY 99 (4 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe value in Display zone 3.

z

Specification:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 174: Scan Tool Display - Throttle Position Sensor, From MY 99 (5 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

0 1 0 (pedal not operated)

0 0 0 (pedal operated)

z

Press accelerator pedal down slowly.

z

Specification: value in zone 2 must increase steadily up to 100% (pedal fully depressed).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 175: Scan Tool Display - Throttle Position Sensor, From MY 99 (6 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

On vehicles with an automatic transmission, the kickdown switch pressure point must be distinctly felt before
the Wide Open Throttle (WOT) stop position is reached.

If specified end value not reached:

z

Replace Throttle Position sensor -G79-

If display does not change or is irregular:

z

Check Throttle Position sensor as follows:

z

Switch OFF ignition.

z

Disconnect harness connector for sensor. See DIESEL INJECTION SYSTEM, COMPONENT



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



LOCATIONS OVERVIEW .

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 176: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness (From MY 99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Check following combinations for open circuits and/or short to positive or negative:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
