z

Wiring between connector terminal 1 and Test Box socket 24.

z

Wiring between connector terminal 2 and Test Box socket 11.

z

Wiring between connector terminal 3 and Test Box socket 23.

z

Wiring between connector terminal 4 and Test Box socket 12.

z

Wiring between connector terminal 5 and Test Box socket 8.

z

Wiring between connector terminal 6 and Test Box socket 25.

From MY 2000

z

Wiring between connector terminal 1 and Test Box socket 63.

z

Wiring between connector terminal 2 and Test Box socket 12.

z

Wiring between connector terminal 3 and Test Box socket 50.

z

Wiring between connector terminal 4 and Test Box socket 69.

z

Wiring between connector terminal 5 and Test Box socket 70.

z

Wiring between connector terminal 6 and Test Box socket 51.

z

Correct any open/short circuit as required.

If neither an open or short circuit exists:

z

Replace Engine Control Module -J248-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Throttle Position (TP) sensor -G79-, checking from MY 99

Throttle Position (TP) sensor -G79- is located on accelerator pedal and communicates physical pedal position to
Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM).

Special tools

z

VAG1551/1552 Scan Tool with VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter, or equivalent

z

VW 1594 Adapter kit

z

Electrical Wiring Diagrams, Troubleshooting & Component Locations

Test sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Switch ON ignition but do not start engine.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):

Fig. 170: Scan Tool Display - Throttle Position Sensor, From MY 99 (1 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 171: Scan Tool Display - Throttle Position Sensor, From MY 99 (2 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 172: Scan Tool Display - Throttle Position Sensor, From MY 99 (3 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press 0, 0 and 2 buttons to select "Display group 2".

z

Press -Q- button to enter input.

z

Observe value in Display zone 2 (Throttle Position).

z

Specification: 0.0% (pedal not operated)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
