z

Specification: 1.0 to 1.5 k ohm

z

Accelerator depressed: wide open throttle

z

Specification: 1.5 to 2.5 k ohm

If specifications not obtained:

z

Replace Throttle Position sensor -G79-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specifications obtained:

z

Switch OFF ignition.

z

Disconnect harness connector for sensor. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW
 .

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 168: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness (Up To MY 99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Check following combinations for open circuits and/or short to positive or negative:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 169: Identifying Throttle Position Sensor Harness Connector Terminals (Up To MY 99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
