4 (Ground) and 20 (road speed signal).

z

Switch ON ignition and turn front left wheel by hand.

z

Voltage tester LED must blink (approx. four times per wheel rotation)

If LED does not blink:

z

Check wiring for open/short circuit between following ECM harness connector terminal and instrument
cluster using Electrical Wiring Diagram.

See appropriate System Wiring Diagram article.

Up to MY 1999

Terminal 51

From MY 2000

Terminal 20

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Throttle Position (TP) sensor -G79-, checking up to MY 99

Throttle Position (TP) sensor -G79- is located on accelerator pedal and communicates physical pedal position to
Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM).

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter, or equivalent

z

VW 1594 Adapter kit

z

Electrical Wiring Diagrams, Troubleshooting & Component Locations

Test sequence

NOTE:

If necessary, hold the front right wheel to prevent it from turning.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING and switch
ON ignition but do not start engine.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):

Fig. 161: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (1 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 162: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (2 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 163: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (3 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press 0, 0 and 2 buttons to select "Display group 2".

z

Press -Q- button to enter input.

z

Observe value in Display zone 2 (Throttle Position).

z

Specification: 0.0% (pedal not operated)
