Fig. 164: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (4 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe value in Display zone 3.

z

Specification:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 165: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (5 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

0 1 0 (pedal not operated)

0 0 0 (pedal operated)

z

Press accelerator pedal down slowly.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Specification: value in zone 2 must increase steadily up to 100% (pedal fully depressed).

Fig. 166: Scan Tool Display - Throttle Position Sensor, Up To MY 99 (6 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

On vehicles with an automatic transmission, the kickdown switch pressure point must be distinctly felt before
the Wide Open Throttle (WOT) stop position is reached.

If specified end value not reached:

z

Adjust Throttle Position sensor -G79-

If display does not change or is irregular:

z

Check Throttle Position sensor as follows:

z

Switch OFF ignition.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Disconnect connector for sensor: Component locations overview. See DIESEL INJECTION SYSTEM,
COMPONENT LOCATIONS OVERVIEW .

z

Carry out resistance measurement between sensor terminals 1 and 3 using Fluke 83 multimeter.

Fig. 167: Identifying Throttle Position Sensor Terminals (Up To MY 99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Accelerator not depressed: Idling speed



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
