Volkswagen New Beetle. Manual - part 1412





Fig. 177: Identifying Throttle Position Sensor Harness Connector Terminals (From MY 99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Wiring between connector terminal 1 and Test Box socket 8.

z

Wiring between connector terminal 2 and Test Box socket 11.

z

Wiring between connector terminal 3 and Test Box socket 23.

z

Wiring between connector terminal 4 and Test Box socket 24.

z

Wiring between connector terminal 5 and Test Box socket 12.

z

Wiring between connector terminal 6 and Test Box socket 25.

z

Correct any open/short circuit as required.

If neither open nor short circuit exists:

z

Replace Engine Control Module -J248-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Transmission range selector signal, checking

The Engine Control Module (ECM) receives the Transmission Range change signal from the Transmission
Control Module (TCM) via the data bus. The ECM briefly reduces the injection quantity and thus reduces the
torque and resulting shift jolt.

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING and start
engine and let idle.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 178: Scan Tool Display - Transmission Range Selector Signal (1 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 179: Scan Tool Display - Transmission Range Selector Signal (2 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
