Specification: approx. battery Voltage

If specification not obtained:

z

Check wiring/connections to -N75-.

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 116: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and harness connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 117: Identifying Wastegate Bypass Regulator Valve -N75- Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 28

z

Terminal 2 + socket 15

From MY 2000

z

Terminal 1 + socket 2

z

Terminal 2 + socket 62

z

Wire resistance: 1.5 ohm maximum



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Check wires for shorting to: one another, Ground and Battery +.

z

Specification: INFINITY ohm

z

Correct any open/short circuit as necessary.

If no open or short circuits exist:

z

Replace Engine Control Module.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Mass Air Flow (MAF) Sensor -G70-, checking

ECM uses MAF Sensor -G70- signal to calculate injection quantity and for regulating EGR. The smaller the -
G70- signal; the smaller the quantity of injected fuel.

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING and start
engine and let idle.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):

WARNING:

For safe operation, use a second technician to operate test equipment
and take readings from back seat, during test drive.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 118: Scan Tool Display - Mass Air Flow Sensor (1 Of 7)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:
