Volkswagen New Beetle. Manual - part 1392





z

Press -Q- button to enter input.

Display will appear as shown

Fig. 112: Scan Tool Display - Boost Pressure Control (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Accelerate vehicle in 3rd gear from about 1500 RPM under Wide Open Throttle.

z

Press PRINT button on VAG1551 at about 3000 RPM.

z

Specification on VAG1551: 1720 to 2300 mbar (Display zone 3)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 113: Scan Tool Display - Boost Pressure Control (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If measured Boost pressure is too low

z

Check -N75- as follows:

Wastegate bypass regulator valve -N75-, electrically checking

z

Switch OFF ignition.

z

Disconnect -N75- harness connector. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Switch Fluke 83 multimeter to resistance range.

z

Measure resistance between -N75- terminals using multimeter.

Fig. 114: Measuring Resistance Between Wastegate Bypass Regulator Valve -N75- Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Specification: 14 to 20 ohm

If specification not obtained:

z

Replace Wastegate Bypass Regulator valve - N75-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Set the readiness code. See READINESS CODE, SETTING .

Wastegate Bypass regulator valve -N75- Voltage supply, checking

z

Switch OFF ignition.

z

Disconnect harness connector off valve. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW
 .

z

Connect Fluke 83 multimeter between terminal 1 and Ground using jumper wires from VW 1594 Adapter
kit.

Fig. 115: Identifying Wastegate Bypass Regulator Valve -N75- Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch Fluke 83 multimeter to 20 Volt range.

z

Switch ON ignition.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
