Volkswagen New Beetle. Manual - part 1364





Fig. 10: Removing Scotch Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pry up unit injector connector with a screwdriver. To avoid canting support other side of connector with
light finger pressure.

Fig. 11: Prying Up Unit Injector Connector With Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Insert puller instead of scotch block into slot of injector unit.

z

Pull injector unit off by knocking it outward of cylinder head seat.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 12: Removing Injector Unit
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

If the old injector unit is installed, the O-rings and heat protection gasket must be replaced, See O-RINGS FOR
INJECTOR UNIT, REMOVING AND INSTALLING
 .

z

Check correct seat of three O-rings, heat protection gasket and safety ring before installing injector unit.

z

Oil O-rings and insert injector unit with greatest care in cylinder head seat.

z

Install injector unit into cylinder head seat onto limit stop by pressing it evenly.

z

Insert scotch block into slot of injector unit.

Align injector unit as follows:

NOTE:

z

If a new injector unit is installed, the respective adjustment screw in the
rocker lever must also be replaced.

z

For every repair which requires an adjustment of the injector unit, the
locker lever adjustment screw and the injector unit ball pin must be
cleaned and checked for wear. If worn replace the ball pin and adjustment
screw.

z

New injector units are supplied with O-rings and heat protection gasket.

NOTE:

The O-rings must not be twisted.

NOTE:

If the injector unit is not positioned at right angles to the scotch block the
securing bolt could loosen and cause damage to the injector unit or the
cylinder head.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



z

Screw new securing bolt into scotch block until injector unit can still be turned lightly.

z

Align injector unit at right angles to bearing pedestals of camshaft.

z

Use a vernier gauge (measuring range at least 400 mm) and check dimension "a" from cylinder head
outer edge to round surface of injector unit. See Fig. 13 and DIMENSION "A" FROM CYLINDER
HEAD OUTER EDGE TO ROUND SURFACE OF INJECTOR UNIT
 .

DIMENSION "A" FROM CYLINDER HEAD OUTER EDGE TO ROUND SURFACE OF
INJECTOR UNIT


Fig. 13: Checking Dimension "a" From Cylinder Head Outer Edge To Round Surface Of Injector
Unit

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align injector unit again, if necessary, and tighten securing bolt as follows:

z

Tighten securing bolt to 12 N.m plus an additional 270° (3/4 turn). Turning further can be done in several
stages.

z

Position rocker shaft and tighten new securing bolts as follows:

Cylinder

Dimension "a"

1

333.0 +/-0.8 mm

2

245.0 +/-0.8 mm

3

153.6 +/-0.8 mm

4

65.6 +/-0.8 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 14: Positioning Rocker Shaft And Tightening New Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten inner bolts -2- first and then outer screws -1- hand-tight. Then in same sequence to:

20 N.m and 90°(1/4 turn further).

z

Install a dial gauge on injector unit adjustment screw as shown in Fig. 15 .

Fig. 15: Installing Dial Gauge On Injector Unit Adjustment Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft in engine direction of rotation, until rocker lever roller is positioned on actuating cam
point.

Roller side (arrow -A-) is at highest point

Dial gauge (arrow -B-) is at lowest point

z

Remove dial gauge.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW
