Volkswagen New Beetle. Manual - part 1363





Fig. 4: Injector Unit Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

Special tools and equipment

z

T10056 Assembly sleeves Removing

Fig. 5: Identifying T10056 Assembly Sleeves
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove injector unit, See INJECTOR UNIT, REMOVING AND INSTALLING .

z

Carefully remove old O-rings from injector unit.

Installing

NOTE:

z

Always use assembly sleeves to install the O-rings. Otherwise the O-rings
will be damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



z

Pull heat protection gasket off together with safety ring.

z

Carefully clean contact surfaces for O-rings at injector unit.

z

Install assembly sleeve T10056/1 on injector unit onto limit stop.

Fig. 6: Installing Assembly Sleeve T10056/1 On Injector Unit Onto Limit Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully slide upper thicker O-ring on assembly sleeve and in injector unit seat.

z

Remove assembly sleeve.

z

Install assembly sleeve T10056/2 on injector unit onto limit stop.

z

Carefully slide center thinner O-ring on assembly sleeve and in injector unit seat.

z

Remove assembly sleeve.

z

Gradual introduction of O-rings without different color identification.
Observe correct application of the O-rings to the grooves: the ring
thickness decreases towards the injector.

z

Avoid rolling movements when sliding onto the O-rings. The O-rings must
not be twisted in the injector unit seat.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 7: Installing Assembly Sleeve T10056/2 On Injector Unit Onto Limit Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install assembly sleeve T10056/3 on injector unit onto limit stop.

Fig. 8: Installing Assembly Sleeve T10056/3 On Injector Unit Onto Limit Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully slide lower O-ring on assembly sleeve and in injector unit seat.

z

Remove assembly sleeve.

z

Slide on a new heat protection gasket together with safety ring.

z

Install injector unit, See INJECTOR UNIT, REMOVING AND INSTALLING .

INJECTOR UNIT, REMOVING AND INSTALLING

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

3410 Socket



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



z

T10054 Socket

z

T10055 Puller

z

V.A.G1331 Torque wrench (5 to 50 N.m)

z

Dial gauge

Fig. 9: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove toothed belt upper part and cylinder head cover. See CYLINDER HEAD, REMOVING AND
INSTALLING
 .

z

Turn crankshaft until cam pair of injector unit to be installed/removed points evenly upward.

z

Loosen adjustment screw lock nuts -1- and unscrew adjustment screws until respective locker lever lies
on injector unit spring. See Fig. 10 .

z

Loosen securing bolts -2- for rocker shaft (starting on outside and working inward) with socket insert
3410 and take rocker shaft off.

z

Loosen scotch block securing bolt -3- with socket insert T10054 and remove scotch block.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW
