Volkswagen New Beetle. Manual - part 1362





5. Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248-

z

With Barometric Pressure (BARO) Sensor -F96-

z

Replacing, See ENGINE CONTROL MODULE

6. Intake Manifold Runner Control (IMRC) Valve -N316-

7. Exhaust Gas Recirculation (EGR) Cooler Switch-over Valve -N345-

8. Wastegate Bypass Regulator Valve -N75-

9. Mass Air Flow (MAF) Sensor -G70-

10. Connector

z

For injector unit (-N240- to -243-)

11. Engine Speed (RPM) Sensor -G28-

12. Fuel Temperature Sensor -G81-

13. Connector

z

For Engine Speed (RPM) Sensor -G28-

14. Connector

z

For Camshaft Position (CMP) Sensor -G40-,

15. Camshaft Position (CMP) Sensor -G40-

z

For camshaft position

16. Manifold Absolute Pressure (MAP) Sensor -G71- with Intake Air Temperature (IAT) Sensor -G72-

Fig. 1: Diesel Direct Injection System Component Locations Overview
Courtesy of VOLKSWAGEN OF AMERICA, INC.

VARIABLE INTAKE MANIFOLD, SERVICING

The variable intake manifold is switched depending on engine speed and accelerator pedal position.

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



1. 22 N.m

2. Connecting pipe

z

From cooler for exhaust gas recirculation. See EXHAUST GAS RECIRCULATION SYSTEM
COMPONENTS, REMOVING AND INSTALLING
 .

3. Seal

z

Always replace

4. Intake manifold upper part

5. O-ring

z

Always replace

6. EGR Vacuum Regulator Solenoid Valve -N18-

7. 10 N.m

8. O-ring

z

Always replace

9. Intake manifold flap

z

With Motor for intake flap -V157-

10. 10 N.m

11. Seal

z

Always replace

12. Seal

z

Always replace.

13. Intake manifold lower part

z

with selector shaft

14. 10 N.m

z

Note tightening sequence. See VARIABLE INTAKE MANIFOLD, DISASSEMBLING AND
ASSEMBLING


15. Bracket

16. 10 N.m

17. Vacuum actuator

18. Vacuum hose

19. Intake Manifold Runner Control (IMRC) Valve -N316-

z

Vacuum hoses for connection diagram. See VACUUM HOSE CONNECTION DIAGRAM



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 2: Exploded View Of Variable Intake Manifold
Courtesy of VOLKSWAGEN OF AMERICA, INC.

VARIABLE INTAKE MANIFOLD, DISASSEMBLING AND ASSEMBLING

z

Remove variable intake manifold.

z

Loosen connecting bolts.

z

Disconnect upper and lower part of intake manifold. Separate both parts with light blows of a rubber
headed hammer if necessary.

z

Clean contact surface.

z

Replace seal.

z

Put upper and lower part of intake manifold together and tighten all connecting bolts hand-tight.

z

Tighten all securing bolts in indicated sequence to 10 N.m.

Fig. 3: Tightening Sequence Of Upper & Lower Intake Manifold Securing Bolts

NOTE:

To avoid distortion of the variable intake manifold it must only be tightened in
the described sequence:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install variable intake manifold.

INJECTOR UNIT, SERVICING

z

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

z

Always replace sealing and O-rings.

1. 20 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

Note sequence when loosening and tightening. See INJECTOR UNIT, REMOVING AND
INSTALLING
 .

2. Rocker shaft

z

With rocker lever

z

Removing and installing, See INJECTOR UNIT, REMOVING AND INSTALLING .

3. Lock nut, 30 N.m

4. Adjustment screw

z

Replace when installing a new injector unit or if worn

z

Adjusting, see INJECTOR UNIT, REMOVING AND INSTALLING

5. Unit injector

z

Check ball pin for wear, replace if necessary

z

Removing and installing, see INJECTOR UNIT, REMOVING AND INSTALLING

6. O-ring

z

Replacing, See O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

7. O-ring

z

Replacing, See O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

8. O-ring

z

Replacing, See O-RINGS FOR INJECTOR UNIT, REMOVING AND INSTALLING

9. Heat protection gasket

z

Always replace

10. Circlip

11. Cylinder head

12. Scotch block

13. 12 N.m plus an additional 3/4 turn (270°)

z

Always replace

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW
