Volkswagen New Beetle. Manual - part 1360





Fig. 190: Scan Tool Display - A/C System Signal To ECM (1 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press --> button.

Display will appear as shown:

Fig. 191: Scan Tool Display - A/C System Signal To ECM (2 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:

Fig. 192: Scan Tool Display - A/C System Signal To ECM (3 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0-, -0- and -2- buttons to select "Display group 2".

z

Press -Q- button to enter input.

Display will appear as shown (1 to 4 = Display zones):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 193: Scan Tool Display - A/C System Signal To ECM (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch ON A/C by pressing "Auto" button and selecting lowest temperature.

z

A/C compressor must run.

z

Observe display in Display zone 3.

If specification not obtained:

z

Specified Value: 1 X 1 (A/C system signal)

Fig. 194: Scan Tool Display - A/C System Signal To ECM (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 195: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between following Test Box socket and A/C system using Wiring diagram.

Up to MY 1999

Socket 48

From MY 2000

Socket 34

z

Wire resistance: 1.5 ohm maximum

CAN-Bus, checking

1. Engine Control Module (ECM)

2. ABS control module

3. Transmission Control Module (TCM)

z

Only vehicles with automatic transmission

4. Airbag control module

5. Instrument cluster

6. CAN-Bus

NOTE:

The following list refers to Fig. 196 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
