Volkswagen New Beetle. Manual - part 1358





Fig. 182: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring between ECM and TCM for open / short circuits.

See appropriate System Wiring Diagram article.

A/C system signals, checking

Special tools



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Checking requirements

z

A/C function OK

z

No malfunctions stored in DTC memory. See DTC MEMORY, CHECKING .

z

Vehicle temperature: +15 °C (59 °F) minimum

z

A/C system switched ON

A/C compressor shut-off, checking

The A/C control head signals the Engine Control Module that the A/C compressor will be switched ON via the
A/C compressor signal.

Using the same wiring, the A/C compressor is switched OFF by the ECM under the following circumstances:

z

Hard acceleration from low speed

z

Engine is running under an emergency program

z

Engine Coolant Temperature exceeds +120 °C (248 °F)

z

During every engine start for approx. 6 seconds.

Checking

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Start engine and let idle.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 183: Scan Tool Display - A/C System Signals (1 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 184: Scan Tool Display - A/C System Signals (2 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -3- buttons to select Function 03: "Output Diagnostic Test Mode".



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
