Volkswagen New Beetle. Manual - part 1337





z

Switch Fluke 83 multimeter to resistance range.

z

Measure resistance between -N75- terminals using multimeter.

Fig. 114: Measuring Resistance Between Wastegate Bypass Regulator Valve -N75- Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Specification: 14 to 20 ohm

If specification not obtained:

z

Replace Wastegate Bypass Regulator valve - N75-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Set the readiness code. See READINESS CODE, SETTING .

Wastegate Bypass regulator valve -N75- Voltage supply, checking

z

Switch OFF ignition.

z

Disconnect harness connector off valve. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW
 .

z

Connect Fluke 83 multimeter between terminal 1 and Ground using jumper wires from VW 1594 Adapter
kit.

Fig. 115: Identifying Wastegate Bypass Regulator Valve -N75- Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch Fluke 83 multimeter to 20 Volt range.

z

Switch ON ignition.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Specification: approx. battery Voltage

If specification not obtained:

z

Check wiring/connections to -N75-.

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 116: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and harness connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 117: Identifying Wastegate Bypass Regulator Valve -N75- Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 28

z

Terminal 2 + socket 15

From MY 2000

z

Terminal 1 + socket 2

z

Terminal 2 + socket 62

z

Wire resistance: 1.5 ohm maximum



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
