z

For repair cases.

z

Marked by three impressions on circumference of exhaust pipe

z

As standard, exhaust pipe and rear mufflers are installed as a single component. In repair cases
exhaust pipe and rear muffler are supplied individually with a double clamp for connecting
together.

z

Cut through connecting pipe with body saw e.g. V.A.G 1523 at right angles at separating point. See
Fig. 5 .

6. Bracket

z

With suspension

7. Muffler

z

Aligning rear muffler free of stress. See Fig. 7 .

8. Mounting

z

With retaining ring.

9. 20 N.m

10. Tunnel bridge

11. 40 N.m



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 2: Identifying Muffler With Mountings
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Double clamp, installation position



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 3: Identifying Double Clamp Installation Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position double clamp approx. 5 mm from mark A (arrow -2-).

Mounting, installation position

NOTE:

z

Mark "A" (arrow -2-) is valid for vehicles with manual and automatic
transmissions.

z

Mark "S" (arrow -1-) is not valid for this engine.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 4: Identifying Mounting, Installation Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Angled side on base of mounting (arrow) points forward.

Exhaust pipe, separating point
