Volkswagen New Beetle. Manual - part 1249





Fig. 5: Identifying Exhaust Pipe, Separating Point
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

Body saw e.g. V.A.G 1523

{

Separate exhaust pipe at right angles at separating point (arrow -2-).

{

When installing, position double clamp -4- on side markings (arrows -1- and -3-).

Tightening torque: 40 N.m



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 6: Positioning Double Clamp On Side Markings While Installing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Aligning rear muffler free of stress

Fig. 7: Aligning Rear Muffler Free Of Stress
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The mounting pins on exhaust pipe must run parallel with tunnel bridge (dimension -x- on left and right the
same).

EXHAUST GAS RECIRCULATION SYSTEM

NOTE:

z

The function/control of the exhaust gas recirculation system is undertaken
by Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248-
via EGR Vacuum Regulator Solenoid Valve -N18-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



EXHAUST GAS RECIRCULATION SYSTEM COMPONENTS, REMOVING AND INSTALLING

1. Bracket

z

For bypass flap for exhaust gas recirculation cooler

2. 22 N.m

3. 5 N.m

4. Intake manifold

z

With Motor for intake flap -V157-

5. O-ring

z

Always replace

6. EGR Vacuum Regulator Solenoid Valve -N18-

z

Removing and installing. See EGR VACUUM REGULATOR SOLENOID VALVE -N18-
,REMOVING AND INSTALLING


7. 10 N.m

8. Seal

z

Always replace

9. Connecting pipe

10. Radiator

z

For exhaust gas recirculation

z

Installing. See EXHAUST GAS RECIRCULATION COOLER, INSTALLING .

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM .

11. Exhaust manifold

z

Can only be replaced completely with turbocharger

z

Removing and installing. See TURBOCHARGER SYSTEM COMPONENTS, REMOVING
AND INSTALLING
 .

12. Seal

z

Always replace

13. Connecting pipe

14. Seal

z

Always replace

z

Pulsed control makes every conceivable valve position possible.

z

Replace self-locking nuts.

z

Vacuum hose connection diagram. See VACUUM HOSE CONNECTION
DIAGRAM .

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION
DIAGRAM .

NOTE:

The following list refers to items in Fig. 8 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



15. Bypass flap

z

Vacuum hoses for connection diagram. See VACUUM HOSE CONNECTION DIAGRAM .

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM .

z

Installing. See EXHAUST GAS RECIRCULATION COOLER, INSTALLING .

Fig. 8: Exploded View Of Intake Manifold, Exhaust Manifold & Exhaust Gas Recirculation System
Components

Courtesy of VOLKSWAGEN OF AMERICA, INC.

EXHAUST GAS RECIRCULATION COOLER, INSTALLING

Special tools and equipment

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

Fig. 9: Identifying V.A.G 1331 Torque Wrench

NOTE:

Description of repair must be observed in order to avoid damages caused
by stress.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW
