Volkswagen New Beetle. Manual - part 1247





Fig. 28: Connecting Test Box VAG 1598/22 To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and harness connector using wiring diagram.

Up to MY 1999

z

Socket 1 + terminals 2 + 28

z

Socket 2 + terminal 29

From MY 2000



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle



z

Socket 1 + terminals 1 + 2

z

Socket 2 + terminal 61

Wire resistance: 1.5 ohms maximum

z

Check wires for short to one another, to vehicle Ground and to battery Positive (+).

Specification: "INFINITE" ohms

If wiring OK:

z

Replace Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248:

See Engine Control Module (ECM), Replacing .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 1.9L 4-Cyl. - ALH, New Beetle



1998-2004 ENGINE

Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW

EXHAUST SYSTEM COMPONENTS, REMOVING AND INSTALLING

FRONT EXHAUST PIPE AND CATALYST WITH COMPONENTS

1. From turbocharger

2. Seal

z

Always replace

3. 25 N.m

z

Always replace

z

Oil threaded studs with G 052 112 A3

4. Front exhaust pipe with catalytic converter

5. To rear muffler

6. Connector

z

Connection in protective housing, on vehicle underside right side

7. Mounting

8. 25 N.m

9. Heated Oxygen Sensor (HO2S) -G39-, 50 N.m

z

Grease only threads with hot bolt paste G 052 112 A3 (anti-seize compound). Grease must not get
into slots on sensor body

z

Remove and install with 3337

z

To remove, separate connection and move wiring aside

NOTE:

z

Removing and installing exhaust manifold. See TURBOCHARGER
SYSTEM COMPONENTS, REMOVING AND INSTALLING .

z

After working on the exhaust system make sure that the system is not
under stress, and that there is sufficient clearance from the bodywork. If
necessary, loosen double and single clamps and align muffler and
exhaust pipe so that sufficient clearance is maintained to the bodywork
and the support rings are evenly loaded.

z

Replace self-locking nuts.

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 1: Front Exhaust Pipe And Catalyst With Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

MUFFLER WITH MOUNTINGS

1. From catalytic converter

2. Double clamp

z

Note installation position. See Fig. 3 .

3. 25 N.m

4. Mounting

z

Note installation position. See Fig. 4 .

5. Separating point

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.9L 4-Cyl. - BEW
