z

Connect hand vacuum pump VAG1390 to vacuum hose -1-.

Fig. 46: Pulling Vacuum Hose Off Secondary Air Injection Solenoid Valve -N112-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove pressure hose -arrow- between secondary air pump motor and connecting pipe and blow in with

NOTE:

Do not use compressed air during the following check!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



slight pressure.

Combi-valve must be closed.

z

Blow into pressure hose with light pressure -arrow-.

Combi-valve must be closed.

z

Operate hand vacuum pump.

Combi-valve must open.

If the combi-valve does not open:

z

Replace corresponding combi-valve. See COMBI-VALVE, REMOVING AND INSTALLING .

Secondary air injection (AIR) pump motor -V101-, checking

Only engine code APH

Engine codes AWP, AWV: See ENGINE CODES AWP, AWV .

Special tools and equipment

z

VAG1527B Diode test lamp

z

VAG1594A Adapter set

z

VAG 1598/31 Test box

NOTE:

To release, press together the buttons on the hose coupling.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 47: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test Conditions

z

Main fuses must be OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 48: Identifying Main Fuses Location
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 V

z

Output Diagnostic Test Mode (DTM) performed

See Output Diagnostic Test Mode (DTM) .

Test sequence

z

Remove engine cover.

z

Remove pressure hose at motor for secondary air injection pump -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
