Volkswagen New Beetle. Manual - part 1236





Fig. 42: Removing And Installing Secondary Air System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Secondary Air Injection (AIR) Pump Relay - J299

Fig. 43: Secondary Air Injection (AIR) Pump Relay - J299
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Secondary air injection system, overview

NOTE:

z

If tools are necessary to remove relays or control modules from the relay
plate, first disconnect battery Ground strap.

z

Before disconnecting battery Ground strap obtain code for radios with
anti-theft coding.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Only engine code APH

For engine codes: AWP, AWV; Check Turbocharging diagram. See ENGINE CODES AWP, AWV

1. Secondary air injection (AIR) solenoid valve -N112-*/**

2. Vacuum reservoir

3. Recirculating valve for turbocharger -N249-

4. Non-return valve

5. Overrun shut-off valve

6. Brake servo

7. Air cleaner with Mass Air Flow (MAF) sensor -G70-

8. Secondary air injection (AIR) pump motor -V101-**

9. Combination valve

10. Fuel pressure regulator

11. Intake pipe

NOTE:

The following list refers to items in Fig. 44 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 44: Overview Of Secondary Air Injection System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Combi-valve, checking

Special tools and equipment

z

VAG1390 Hand vacuum pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 45: Identifying VAG1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test conditions

z

Output Diagnostic Test Mode (DTM) carried out

See Output Diagnostic Test Mode (DTM) .

z

Vacuum lines and hose connections free of leaks

z

Vacuum lines not blocked/kinked

Test sequence

z

Remove engine cover.

z

Pull vacuum hose -1- off secondary air injection solenoid valve -2- -N112-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
