DISPLAY ZONES

If the display does not indicate as described:

z

Remove engine speed adjuster VAG1788/10 from accelerator pedal.

z

Press --> key.

z

Check DTC memory:

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing .

z

Read out readiness code:

See Readiness Code, Displaying .

If DTC memory has been erased or the engine control module separated from the permanent positive, the
readiness code must be generated again.

See Readiness Code, Displaying .

If the display indicates as described:

z

Press C key.

Indicated on display:



Display zones

1

2

3

4

Display group 34: Oxygen sensor aging diagnostic Bank 1 (sensor dynamics)
Display

xxxx RPM

xxx.x° C

xx.xx

Test OFF/Test ON

B1-S1 OK/B1-S1 n.OK

Indicated

Engine speed (in

steps of 40)

Catalyst

temperature

Sensor dynamics Bank 1

oxygen sensor 1

Diagnostic condition and

diagnostic result

Working
range

0 to 6800 RPM

-

0.00 to 1.99

-

Specified
value

1800 to 2200

RPM

> 350 °C

> 0.50

B1-S1 OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 39: V.A.G 1551 Scan Tool Display - Checking Catalyst (4 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press keys 0, 4 and 6 for "display group number 46" and confirm entry with Q key.

Indicated on display: (1-4 = Display zones)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 40: V.A.G 1551 Scan Tool Display - Checking Catalyst (5 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



z

Maintain engine speed at 1800 to 2200 RPM until catalyst temperature in display zone 2 increases to
above 440° C.

If the diagnostic is initiated from engine control module the display in display zone 4 jumps from "Test OFF" to
"Test ON."

z

Check catalyst conversion (amplitude condition) in display zone 3:

Specification: max. 0.20

z

Continue to maintain speed at 1800 to 2200 RPM until the specification "Cat B1 OK." appears in display
zone 4.

DISPLAY ZONES

If the display does not indicate as described:

z

Remove engine speed adjuster VAG1788/10 from accelerator pedal.

z

Press --> key.

z

Check DTC memory:

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing .

z

Read readiness code:

See Readiness Code, Displaying .

If the DTC memory has been erased or the engine control module separated from permanent positive, the
readiness code must be generated again.

NOTE:

This process can take a few minutes. If no result is displayed within 15
seconds, change RPMs within specified range.



Display zones

1

2

3

4

Display group 46: Catalyst diagnostic Bank 1
Display

xxxx RPM

xxx.x °C

x.xx

Test OFF/Test ON Cat B1

OK.

Cat B1 n. OK.

Indicated

Engine speed (in

steps of 40)

Catalyst

temperature

Catalyst conversion

(amplitude condition)

Diagnosis condition and

Diagnosis result

Working
range

0 to 6800 RPM

-

0.00 to 1.00

-

Specified
value

1800 to 2200

RPM

Min.440° C

Max. 020

Cat B1 OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
