Volkswagen New Beetle. Manual - part 1232





Installation Position Of Mount

Fig. 32: Identifying Installation Position Of Mount
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Angled side on foot of mount (-arrow-) points forward.

Separating Point On Exhaust Pipe



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 33: Identifying Separating Point On Exhaust Pipe
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Separate exhaust pipe at right angles at separating point -arrow 2-.

z

When installing fit repair type double clamp -4- at side markings -arrows 1 and 3-.

Tightening torque: 40 N.m

Aligning Central Muffler Stress Free



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 34: Aligning Central Muffler Stress Free
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The support pin on exhaust pipe must align parallel with tunnel bridge (dimension -x- on left and right the



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



same).

Catalyst, checking

Special tools and equipment

z

VAG1551 Scan tool

z

VAG1551/3B Cable

z

VAG1788/10 speed regulator

NOTE:

The VAG1552 vehicle system tester can be used instead of the VAG1551
Scan Tool, but a print-out is not possible.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
