Volkswagen New Beetle. Manual - part 1231





Fig. 29: Identifying Components Of Exhaust Manifold, Front Exhaust Pipe And Catalyst With
Attachments

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Muffler with mounts

1. From catalyst

2. Double clamp

z

Note installation position. See Checking Installation Position Of Double Clamp

3. 25 N.m

4. Mount

z

Note installation position. See Installation Position Of Mount

NOTE:

The following list refers to items in Fig. 30 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



5. Center muffler

z

Aligning. See Aligning Central Muffler Stress Free

6. Separating point

z

As standard, center and rear mufflers are installed as a single component. In cases of repair the
center and rear muffler are supplied individually and with a double clamp for connecting

z

Cut through connecting pipe with body saw e.g. VAG1523at right angles at the separating point.
See Separating Point On Exhaust Pipe

7. Mount

8. Bracket

9. Rear muffler

10. Mount

z

With retaining ring

11. 20 N.m

12. Tunnel bridge

13. 40 N.m

14. Washer



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 30: Identifying Muffler With Mounts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Installation Position Of Double Clamp



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 31: Checking Installation Position Of Double Clamp
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position double clamp with approx. 5 mm clearance to the appropriate marking.

z

Marking A (-arrow 1 -) for vehicles with automatic transmission

z

Marking S (-arrow 2-) for vehicles with manual transmission



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
