Volkswagen New Beetle. Manual - part 1229





Fig. 24: Disconnecting Connector From Wastegate Bypass Regulator Valve N75
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



z

Start engine and raise to maximum speed briefly by operating throttle.

Operating rod -2- for Wastegate Bypass Regulator Valve must move.

Fig. 25: Checking Charge Pressure Control Valve Lever For Ease Of Movement
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If the operating rod does not move:

z

Check charge pressure control valve lever -1- for ease of movement. When corroded together, replace
turbocharger.

If the operating rod does not move, even though the lever is free to move:

z

Replace exhaust turbocharger. See Turbocharger with attachments, removing and installing Part II ,
item 6.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



z

Check DTC memory.

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing .

z

Read readiness code.

See Readiness Code, Displaying .

If the DTC memory has been erased or the Engine Control Module separated from the permanent (battery)
positive, the readiness code must be generated again.

See Readiness Code, Displaying .

Charge pressure bypass valve, checking

Special tools and equipment

z

VAG 1390 Hand vacuum pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 26: Identifying VAG 1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test conditions



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)
