Volkswagen New Beetle. Manual - part 1209





Fig. 103: Removing Oil Seal Using Special Tool 2085
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Before installing, remove oil remains from crankshaft journal with a clean cloth.

z

Install guide sleeve 3241/2 onto camshaft journal.

NOTE:

Gradual introduction of PTFE (Teflon) oil seal (identifying characteristics: no
annular spring, sealing lip wider). The sealing lip of this oil ring must not be
oiled or lubricated. A plain encased seal of older construction (with annular
spring) may be replaced with a PTFE oil seal, but not vice versa.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 104: Installing Guide Sleeve 3241/2 Onto Camshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press seal in onto stop with press sleeve 3241/1 and bolt 3241/5.

Fig. 105: Pressing Seal In Onto Stop With Press Sleeve 3241/1 And Bolt 3241/5



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Courtesy of VOLKSWAGEN OF AMERICA, INC.

The rest of the assembly is basically a reverse of the disassembling sequence.

Installing toothed belt and adjusting timing. See TOOTHED BELT, REMOVING, INSTALLING AND
TENSIONING
 .

Oil seal on Camshaft Position (CMP) sensor, removing

Special tools and equipment

z

2085 Oil seal extractor

z

3241 Seal installer (for seal in standard version with annular spring)

z

T10071 Puller (for seal in PTFE-version)

z

VAG1331 Torque wrench (5 to 50 N.m)

z

VAG1332 Torque wrench (40 to 200 N.m)

z

Bolt M8 X 60

Fig. 106: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Pull connector off Camshaft Position (CMP) sensor -G40- -arrow-.

Fig. 107: Pulling Connector Off Camshaft Position Sensor G40
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove toothed belt guard (upper part).

z

Remove housing for Camshaft Position (CMP) sensor.

z

Remove washer and hood for Camshaft Position (CMP) sensor.

z

Screw bolt 2085/1 into camshaft onto stop by hand, to guide seal extractor.

Fig. 108: Screwing Bolt 2085/1 Into Camshaft Onto Stop By Hand To Guiding Seal Extractor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew inner part of oil seal extractor 2085 two turns (approx. 3 mm) out of outer part and lock in
position with knurled screw.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
