Volkswagen New Beetle. Manual - part 1207





Fig. 96: Identifying Sealing Transition Points Between Double Bearing Cap And Cylinder Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully apply a thin coat of sealant D 454 300 A2 to both edges of sealing surfaces between double
bearing cap and cylinder head -arrows- using a small screwdriver.

Sealing transition points between chain tensioner/cylinder head



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 97: Identifying Sealing Transition Points Between Chain Tensioner/Cylinder Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully apply a thin coat of sealant "D 454 300 A2" to both edges of sealing surfaces between camshaft
adjuster and cylinder head -arrows- using a small screwdriver.

Valve seats, refacing

Special tools and equipment

z

Depth gauge

z

Valve seat refacing tool

NOTE:

z

When repairing engines with leaking valves, it is not sufficient to replace
or replace valve seats and valves. It is also necessary to check the valve
guides for wear. This particularly important on high mileage engines. See

VALVE GUIDES, CHECKING

 .

z

The valve seats should only be reworked just enough to produce a perfect
seating pattern. The maximum permissible reworking dimension must be
calculated before reworking commences. If the reworking dimension is
exceeded, the function of the hydraulic lifters can no longer be guaranteed
and the cylinder head should be replaced.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



The max. permissible reworking dimension is calculated as follows:

z

Insert valve and press firmly against seat.

z

Measure distance between end of valve stem and upper edge of cylinder head.

Fig. 98: Measuring Distance Between End Of Valve Stem And Upper Edge Of Cylinder Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Calculate max. permissible reworking dimension from measured distance and minimum dimension.

Minimum dimension:

Outer intake valves: 34.0 mm

Center intake valve: 33.7 mm

Exhaust valve: 34.4 mm

Measured distance minus minimum dimension = max. permissible reworking dimension.

Example:

CALCULATING PERMISSIBLE REWORKING DIMENSION

NOTE:

If the valve is to be replaced as part of a repair, use a new valve for the
calculation.

Measured distance

34.4 mm

- Minimum dimension

34.0 mm

= max. perm. rework dimension

(1)

0.4 mm

(1)

The max. permissible reworking dimension is shown on illustrations for refacing valve seats as



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Reworking intake valve seat

Fig. 99: Reworking Valve Seat Dimensions
Courtesy of VOLKSWAGEN OF AMERICA, INC.

a = 26.2 mm diameter

b = Max. permissible reworking dimension

c = 1.5- 1.8 mm

Z = Cylinder head lower edge

"ALPHA" = 45° valve seat angle

"BETA" = 30° upper correction angle

"GAMMA" = 60° lower correction angle

Reworking exhaust valve seat

a = 29.0 mm diameter

dimension "b."

NOTE:

Calculating max. permissible reworking dimension. See VALVE SEATS,
REFACING .
