Volkswagen New Beetle. Manual - part 1208





b = Max. permissible reworking dimension

c = Approx. 1.8 mm

Z = Cylinder head lower edge

"ALPHA" = 45° valve seat angle

"BETA" = 30° upper correction angle

"GAMMA" = 60° lower correction angle

Camshaft oil seal, replacing

Special tools and equipment

z

VAG1331 Torque wrench (5-50 N.m)

z

VAG1332 Torque wrench (40-200 N.m)

z

3036 Counter hold tool

z

3241 Fitting sleeves

z

2085 Oil seal extractor

NOTE:

Calculating max. permissible reworking dimension. See VALVE SEATS,
REFACING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 100: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing oil seal on camshaft sprocket

z

Remove seal on Camshaft Position (CMP) sensor. See OIL SEAL ON CAMSHAFT POSITION
(CMP) SENSOR, REMOVING
 .

z

Remove toothed belt guard (upper part).

z

Set camshaft sprocket to TDC No. 1 cylinder by turning crankshaft. Mark on camshaft sprocket must
align with mark on cylinder head cover.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 101: Aligning Mark On Camshaft Sprocket With Mark On Cylinder Head Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cylinder head cover.

z

Release tensioner and remove toothed belt from camshaft sprocket.

z

Turn crankshaft back slightly.

z

Remove camshaft sprocket. When loosening camshaft sprocket bolt counter-hold with 3036.

z

Remove woodruff key from camshaft.

z

Screw camshaft sprocket securing bolt -arrow- into camshaft onto stop by hand, to guide seal extractor.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 102: Screwing Camshaft Sprocket Securing Bolt Into Camshaft Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew inner part of oil seal extractor 2085 two turns (approx. 3 mm) out of outer part and lock in
position with knurled screw.

z

Lubricate threaded head of oil seal extractor, place it in position and exerting firm pressure screw it into
oil seal as far as possible.

z

Loosen knurled screw and turn inner part of extractor against camshaft until oil seal has been extracted.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
