Volkswagen New Beetle. Manual - part 1210





z

Lubricate threaded head of oil seal extractor, place it in position and exerting firm pressure screw it into
oil seal as far as possible.

Fig. 109: Lubricating Threaded Head Of Oil Seal Extractor And Placing In Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen knurled screw and turn inner part of extractor against camshaft until oil seal has been extracted.

Installing

Installing PTFE seal

z

Remove oil remains from crankshaft journal with a clean cloth.

z

Install guide sleeve T10071/5 onto camshaft journal.

NOTE:

Gradual introduction of PTFE (Teflon) oil seal (identifying characteristics: no
annular spring, sealing lip wider). The sealing lip of this oil ring must not be
oiled or lubricated. A plain encased seal of older construction (with annular
spring) may be replaced with a PTFE oil seal, but not vice versa.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 110: Installing Guide Sleeve T10071/5 Onto Camshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press seal in onto limit stop using press sleeve T10071/3 and bolt M8 x 60 -1-.

Fig. 111: Pressing Seal In Onto Limit Stop Using Press Sleeve T10071/3 And Bolt M8 X 60
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing seal with annular spring

z

Lightly oil sealing lip of oil seal.

z

Install guide sleeve 3241/2 onto camshaft journal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 112: Installing Guide Sleeve 3241/2 Onto Camshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press seal in onto stop with press sleeve 3241/1 and bolt 3241/3.

Fig. 113: Pressing Seal In Onto Stop With Press Sleeve 3241/1 And Bolt 3241/3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continued for all seals

z

Insert Camshaft Position (CMP) sensor hood into notch in inlet camshaft.

z

Install washer (taper facing outward) and tighten securing bolt to 25 N.m.

z

Install housing for Camshaft Position (CMP) sensor and tighten to 10 N.m.

z

Install upper toothed belt guard.

z

Reconnect connector on Camshaft Position (CMP) sensor -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 114: Reconnecting Connector On Camshaft Position Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Hydraulic lifters, checking

Special tools and equipment

z

Feeler gauge

z

Wood or plastic wedge

Test sequence

z

Start engine and run until radiator fan has switched on once.

z

Increase engine speed to about 2500 RPM for approx. 2 minutes.

If the hydraulic lifters are still noisy, locate faulty lifters as follows:

z

Remove cylinder head cover.

z

Rotate crankshaft clockwise, until cam of tappet to be checked is pointing upward.

z

Determine play between cam and hydraulic lifter.

If the play is in excess of 0.2 mm, replace hydraulic lifter. If the play is less than 0.1 mm or no play, proceed
with check as follows:

z

Push hydraulic lifter down lightly with a wooden or plastic wedge. If when hydraulic lifter is pushed
down a 0.2 mm thick feeler gauge can be pushed between camshaft and hydraulic lifter, hydraulic lifter is
to be replaced.

NOTE:

z

Replace faulty lifter complete (cannot be adjusted or repaired).

z

Irregular valve noises when starting engine are normal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)
