Volkswagen New Beetle. Manual - part 1158





Coil spring seals

z

Lightly oil sealing lip of oil seal.

z

Mount guide sleeve from 2080 A onto crankshaft journal.

Fig. 41: Mounting Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press seal against limit stop using press sleeve from 3266. To do this, use old center bolt for crankshaft
toothed belt sprocket:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 42: Pressing Oil Seal (Coil Spring Seal)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press seal against limit stop.

Continuation for all seals

z

Install crankshaft toothed belt pulley and counter support with 3415.

z

Tighten new center bolt to 90 N.m plus 90° (1/4 turn) further (turning further can be done in several
stages).

NOTE:

Thread and shoulder must be free of oil and grease.
Installing toothed belt and adjusting timing. See TOOTHED BELTS,
REMOVING, INSTALLING AND TENSIONING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 43: Installing Crankshaft Toothed Belt Pulley And Counter Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

Front sealing flange, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

For PTFE seals:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

3415 Counter support

z

T10053 Assembly device

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

V.A.G 1332 Torque wrench (40...200 N.m)

z

Hand drill with plastic brush attachment

z

D 176 404 A2 Silicone sealant

z

Flat scraper

Fig. 44: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

For coil spring seals:

z

2080 A Installation sleeve

z

3415 Counterhold



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
