Fig. 37: Removing Crankshaft Oil Seal (Pulley End)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

NOTE:

A PTFE seal (Teflon) -2- is gradually being introduced instead of the inner coil
spring seal -1-. This has a wider sealing lip. PTFE oil seals are installed free of
oil and grease. When a PTFE seal is installed, then only such a seal may be
installed as a replacement part!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 38: Identifying Oil Seals (Crankshaft, Pulley End)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Before installing, remove oil remains from crankshaft journal with a clean cloth.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



PTFE sealing rings

z

Mount guide sleeve T10053/1 onto crankshaft journal.

Fig. 39: Mounting Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve onto crankshaft journal.

z

Press in oil seal onto limit stop using press sleeve T10053 and bolt T10053/2 (M16 x 1.5 x 60).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 40: Pressing In Crankshaft Front Oil Seal (PTFE)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
