Volkswagen New Beetle. Manual - part 1155





Fig. 30: Sealing Flanges And Flywheel/Drive Plate (Engine Codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Differences Between Sealing Rings



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 31: Identifying Differences Between Sealing Rings
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Installation position of intermediate plate

NOTE:

z

For clarity reasons, individual sealing rings for sealing flange are also
shown. Only replace sealing flange complete with oil seal.

z

A PTFE seal (Teflon) -2- is gradually being introduced instead of the inner
coil spring seal -1-. This has a wider sealing lip.

z

PTFE oil seals are installed free of oil and grease.

z

A radial shaft seal of older design (with annular spring) may be replaced
with a PTFE oil seal, but not vice versa.

z

When a PTFE seal is installed, then only such a seal may be installed as a
replacement part!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 32: Installing Intermediate Plate Onto Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Install intermediate plate onto sealing flange and slide onto dowel sleeves (arrows).

Crankshaft oil seal - pulley end, replacing

Special tools, equipment, testers, measuring instruments and auxiliary items required

For coil spring seals:

z

2080 A Fitting sleeve

z

3203 Oil seal extractor

z

3266 Fitting sleeve

z

3415 Counterhold

z

V.A.G 1331 Torque wrench (5 ... 50 N.m)

z

V.A.G 1332 Torque wrench (40 ... 200 N.m)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
