Volkswagen New Beetle. Manual - part 1153





Fig. 26: Locking Ribbed (Drive) Belt Tensioning Element
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Remove ribbed belt.

Installing

z

Install in reverse order.

After completing repairs always:

z

Start engine and check belt running.

Belt drive without air conditioning compressor

NOTE:

z

Ensure, before installing ribbed belt, that all ancillaries (Generator,
air conditioning compressor, power steering pump) are secured
tightly.

z

When installing the ribbed belt observe belt direction of rotation and
that the belt is seated correctly in the belt pulleys.

z

On models which do not have an air conditioning system place the
ribbed belt over the Generator pulley last.

z

For models with an air conditioning system place the ribbed belt over
the air conditioning compressor last.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 27: Identifying Belt Drive Without Air Conditioning Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Belt drive with air conditioning compressor



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 28: Identifying Belt Drive With Air Conditioning Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SEALING FLANGES AND FLYWHEEL/DRIVE PLATE, REMOVING AND INSTALLING

Engine codes AEG, AVH, AZG, BEV

1. 90 N.m + 1/4 turn (90°) further

z

Replace

z

Threads and shoulder must be free of oil and grease

z

Use counterhold tool 3415 to loosen and tighten

2. Crankshaft toothed belt sprocket

NOTE:

The following list refers to items in Fig. 29 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
