Volkswagen New Beetle. Manual - part 1152





z

For ribbed belt tensioning roller, Generator, power steering pump and air conditioning compressor

See CONDENSER, REMOVING AND INSTALLING .

31. Cylinder block

z

Removing and installing sealing flange and flywheel/drive plate. See SEALING FLANGES AND
FLYWHEEL/DRIVE PLATE, REMOVING AND INSTALLING
 .

z

Removing and installing crankshaft. See CRANKSHAFT, REMOVING AND INSTALLING .

z

Disassembling and assembling piston and conrod. See PISTON AND CONNECTING ROD,
DISASSEMBLING AND ASSEMBLING
 .

z

Engine codes BDC, BGD: Removing and installing oil pump with balancer shaft gear assembly.
See OIL PUMP WITH BALANCER SHAFT GEAR ASSEMBLY, REMOVING AND
INSTALLING
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 23: Exploded View - External Engine Block Components (Part II)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Ribbed belt, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

T20167 Locking pin



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 24: Identifying Special Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove right side insulation tray:

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Remove engine cover.

z

Mark direction of rotation of ribbed belt.

z

Turn tensioning device in direction of arrow to relieve tension on ribbed belt.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 25: Relieving Tension On Ribbed (Drive) Belt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lock tensioning element using locking pin T20167



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
