Volkswagen New Beetle. Manual - part 1150





Fig. 20: Securing Air Conditioning Compressor To Towing Eye
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ENGINE - CRANKSHAFT, CYLINDER BLOCK

ENGINE, DISASSEMBLING AND ASSEMBLING

NOTE:

If when repairing an engine, metal shavings or large amounts of small metal
particles are found in the engine oil, caused for example by partial seizure of



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Only engine codes BDC, BGD

z

The balancer shaft gear assembly must be adjusted. See OIL PUMP WITH BALANCER SHAFT
GEAR ASSEMBLY, REMOVING AND INSTALLING

crankshaft or conrod bearings. Perform the following work sequences to
prevent consequential damage once repairs are complete:

z

Thoroughly clean oil passages

z

Replace oil spray jets

z

Replace oil cooler

z

Replace oil filter



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 21: Disassembling And Assembling Engine (Parts I & II)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



I. See PART I

II. See PART II

Part I

1. 45 N.m

2. Engine bracket

3. 25 N.m

4. Retainer

z

According to engine versions

5. Retainer

z

According to engine versions

6. Clamp

7. 10 N.m

z

For engine cover

z

According to engine versions

8. 20 N.m

z

According to engine versions

9. Toothed belt guard-upper part

10. Toothed belt guard, center section

11. 20 N.m

12. Washer

13. Tensioner

z

Checking semiautomatic toothed belt tensioning roller. See SEMI-AUTOMATIC TOOTHED
BELT TENSIONING ROLLER, CHECKING
 .

14. Toothed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING


15. Rear toothed belt guard

16. Washer

17. O-ring

z

Replace

18. Coolant pump

z

Check for ease of movement

NOTE:

The following list refers to items in Fig. 22 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
