Fig. 18: Identifying Transmission Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Mounting to body

40N.m + 90° (1/4 turn)

Replace bolts

NOTE:

The following list refers to items in Fig. 18 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



2. Mounting to body

25 N.m

3. Mounting to transmission console

100 N.m

Pendulum support



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 19: Identifying Pendulum Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 19 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



1. Pendulum support to transmission

40 N.m + 90° (1/4 turn)

Replace bolts

2. Pendulum support to transmission

40 N.m + 90°(1/4 turn)

Replace bolts

3. Pendulum support to subframe

20 N.m + 90° (1/4 turn)

Replace bolts

Additional information and assembly work on models with an air conditioning system

To facilitate removal and installation of the engine without having to open the refrigerant circuit:

z

Remove retaining clamp(s) from refrigerant lines.

z

Remove air conditioning compressor:

See CONDENSER, REMOVING AND INSTALLING .

z

Secure air conditioning compressor to towing eye so that refrigerant lines/hoses are not under tension.

CAUTION: The air conditioning refrigerant circuit must not be opened.

NOTE:

To prevent damage to the condenser as well as to the refrigerant lines/hoses,
ensure that lines and hoses are not stretched, kinked or bent.

NOTE:

Protect bumper with tape to prevent damage.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
