Volkswagen New Beetle. Manual - part 1151





z

If damaged or leaking renew complete

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING .

19. 15 N.m

20. Crankshaft toothed belt sprocket

21. 90 N.m + 1/4 turn (90°) further

z

Replace

z

Threads and shoulder must be free of oil and grease

z

Use counter support tool 3415 to loosen and tighten

22. Toothed belt guard, lower part

23. 10 N.m

z

Replace

24. Clutch

z

For air conditioning compressor

25. Belt pulley

z

For power steering pump

26. Ribbed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing and installing. See RIBBED BELT, REMOVING AND INSTALLING .

27. Belt pulley/vibration damper

z

Can only be installed in one position. Holes are offset

z

Note position when installing toothed (timing) belt. See TOOTHED BELTS, REMOVING,
INSTALLING AND TENSIONING
 .

28. 25 N.m

29. Tensioning element for ribbed belt

z

Turn with open end wrench to loosen ribbed belt. See RIBBED BELT, REMOVING AND
INSTALLING
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 22: Exploded View - Front Of Engine Components (Part I)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Part II

1. Knock Sensor (KS) 1 -G61-

z

Gold plated contacts

2. Connector

z

For KS 1 -G61-

z

Gold plated contacts

z

Do not interchange

See appropriate System Wiring Diagram article

3. 20 N.m

z

Torque setting influences function of knock sensor

4. Connector

z

For KS 2 -G66-

z

Gold plated contacts

z

Do not interchange

See appropriate System Wiring Diagram article

5. Knock Sensor (KS) 2 -G66-

z

Gold plated contacts

6. Dipstick guide

7. Dipstick

z

The oil level must not exceed the max. mark!

z

Markings. See Fig. 136

8. Coolant pipe

z

According to engine versions

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM .

9. 25 N.m

10. Retainer

z

For ignition coil

11. Retainer

z

According to engine versions

12. 10 N.m

13. Retainer

z

According to engine versions

NOTE:

The following list refers to items in Fig. 23 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



14. Retainer

z

According to engine versions

15. Retainer

z

According to engine versions

16. Oil filter bracket

z

Disassembling and assembling. See Part II (Oil filter housing, disassembling and assembling) .

17. 15 N.m + 1/4 turn (90°) further

z

Replace

18. Seal

z

Replace

19. Oil filter

z

Loosen with strap wrench

z

Tighten by hand

z

Note instructions on filter when installing

20. 25 N.m

21. Oil cooler

z

Coat contact surfaces to oil filter bracket outside the seal with AMV 188 100 02

z

Ensure clearance to adjacent components. See note at beginning of ENGINE, DISASSEMBLING
AND ASSEMBLING
 .

22. Seal

z

Replace

23. Engine speed sensor

24. Seal

z

Replace if damaged

25. 40 N.m

26. Connecting unions

27. 15 N.m

28. Coolant thermostat

z

Checking: Heat up thermostat in water

z

Starts to open at approx. 86° C

z

Opening stroke: min. 7 mm

z

Removing and installing. See THERMOSTAT, REMOVING AND INSTALLING .

29. Hex socket head bolt

z

Torque setting:

See CONDENSER, REMOVING AND INSTALLING .

30. Compact bracket



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
