Fig. 33: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

For PTFE seals:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 34: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

3203 Oil seal extractor

z

3415 Counter support

z

T10053 Assembly device

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

V.A.G 1332 Torque wrench (40...200 N.m)

Removing

z

Remove ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove toothed (timing) belt. See TOOTHED BELTS, REMOVING, INSTALLING AND
TENSIONING
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Remove crankshaft toothed belt pulley. To do this counter support sprocket with 3415.

Fig. 35: Removing Crankshaft Toothed Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To guide seal extractor, thread center bolt into crankshaft onto limit stop by hand.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 36: Installing Bolt Into Crankshaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew inner part of oil seal extractor 3203 nine turns (approx. 20 mm) out of outer part and lock with
knurled screw.

z

Lubricate threaded head of oil seal extractor 3203, place it in position and exerting firm pressure screw it
as far as possible into oil seal.

z

Loosen knurled screw and turn inner part against crankshaft until oil seal is pulled out.
