V.A.G 1331 Torque wrench (5 ... 50 N.m)

z

V.A.G 1332 Torque wrench (40 ... 200 N.m)

z

Hand drill with plastic brush attachment

z

D 176 404 A2 Silicone sealant

z

Flat scraper

Fig. 45: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

z

Remove tensioning element for ribbed belt.

z

Remove toothed (timing) belt. See TOOTHED BELTS, REMOVING, INSTALLING AND
TENSIONING
 .

z

Remove crankshaft toothed belt pulley. To do this counter support sprocket with 3415.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 46: Removing Crankshaft Toothed Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drain engine oil.

z

Remove oil sump. See OIL SUMP, REMOVING AND INSTALLING .

z

Unbolt front sealing flange.

z

Take off sealing flange, release using light blows with a rubber headed hammer if necessary.

z

Remove sealant residue from cylinder block with a flat scraper.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 47: Removing Sealant Remains On Front Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Cover oil seal with a clean cloth.

z

Remove sealant remains on sealing flange with a rotating plastic brush (wear protective goggles).

z

Clean sealing surfaces. Surfaces must be free of oil and grease.

Installing

z

Cut off tube nozzle at front marking (nozzle approx. 3 mm diameter).

z

Apply silicone sealing compound, as shown, to clean sealing surface of sealing flange.

z

Thickness of sealant bead (arrows): 2 ... 3 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 48: Applying Silicone Sealing Compound To Sealing Surface Of Front Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

Before applying sealing bead, cover the oil seal with a clean
cloth.

z

The sealing compound bead must not be thicker, otherwise
excessive sealing compound will enter the sump and may block
