Fig. 45: Installing Sealing Ring
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install crankshaft toothed belt sprocket and hold using 3099 counterhold.

z

Install toothed belt and tension. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING

z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING

Drive plate, removing and installing

Special tools and equipment

z

VW 558 Counter-hold tool

z

Hex bolt M8x45 and two M10 hex nuts

z

Depth gauge



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 46: Identifying VW 558 Counter-Hold Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Drive plate, loosening and tightening

z

Secure VW 558 counterhold to drive plate using M8 x 45 hex bolt.

z

Place two M10 hex nuts between counterhold and drive plate.

Position of counterhold tool:

z

A - To loosen

z

B - To tighten

Fig. 47: Holding Drive Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Drive plate, installing

z

Position drive plate and backing plate with recesses -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Install new bolts -3- and tighten.

z

30 N.m (22 ft lb)

Fig. 48: Installing Drive Plate And Backing Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check dimension -a- at three points and calculate average.

Specification: 19.5 to 21.1 mm

Fig. 49: Checking Drive Plate Installed Dimension
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If specification not obtained

z

Remove drive plate and install shim -2-.

NOTE:

Because of the hole in the drive plate it is measured on the milled surface
of the engine block



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Tighten bolts -3-.

z

30 N.m (22 ft lb)

z

Tighten bolts -3- to 60 N.m (44 ft lb) and turn an additional 90° (1 /4 turn) further.

Fig. 50: Installing Drive Plate And Shim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Sealing flange (front), removing and installing

Special tools and equipment

z

2080 A Sleeve

z

3415 Counter support

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

z

VAG 1332 Torque wrench: 40 to 200 N.m (30 to 148 ft lb)

z

Hand drill w/ plastic brush insert

z

D 176 404 A2 Silicone sealant

z

Flat scraper

NOTE:

The 1/4 turn additional can be achieved in more than one step.
