Remove 2065A setting bar from camshaft.

z

Remove pin.

z

Turn crankshaft two rotations in engine direction of rotation and set again to cylinder 1 TDC.

z

Attach bracket to engine block.

z

Install engine mount (replace mounting bolts).

z

Tightening torque: 40 N.m (30 ft lb) plus additional 90° (1/4 turn)

z

Securely install mount for engine to engine bracket (replace mounting bolts)

z

Tightening torque: 60 N.m (44 ft lb) plus additional 90° (1/4 turn)

z

Install bracket for subassembly/body

z

Tightening torque: 25 N.m (18 ft lb)

z

Install vacuum pump.

z

Install toothed belt guard, vibration damper, belt pulley, and valve cover.

z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Install sound dampening tray and engine cover

z

Remove pipe between charge air cooler and turbocharger. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING
 .

z

Install fuel filter with bracket

z

Disconnect fuel supply and return lines at fuel filter.

z

Install pipe between charge air cooler and intake pipe. See CHARGE AIR COOLER COMPONENTS,
REMOVING AND INSTALLING
 .

z

Check Diesel injection pump "start of delivery"

See START OF INJECTION, DYNAMICALLY CHECKING AND ADJUSTING

Semi-automatic toothed belt tensioning roller, checking

Test sequence

z

Tighten toothed belt with firm thumb pressure.

z

The mounting bolts should only be used one time, since by design
they have a reduced shank



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 39: Tightening Toothed Belt Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Notch and raised portion (arrows) must move apart.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Release thumb pressure on toothed belt.

Tensioning roller must move back to its initial position, notch and raised portion must align again.

SEALING FLANGE AND FLYWHEEL/DRIVE PLATE, REMOVING AND INSTALLING

1. 15 N.m (11 ft lb)

2. Oil seal

z

Replacing. See SEALING RING (CRANKSHAFT PULLEY SIDE), REPLACING

3. Sealing flange, front

z

Must be located on dowel sleeves

z

Removing and installing. See SEALING FLANGE (FRONT), REMOVING AND
INSTALLING


4. Engine block

z

Crankshaft, removing and installing. See CRANKSHAFT, REMOVING AND INSTALLING

z

Pistons and connecting rods, disassembling and assembling. See PISTONS AND CONNECTING
RODS, DISASSEMBLING AND ASSEMBLING


5. Flywheel/drive plate

z

to remove and install flywheel, counter-hold using 3067

z

Drive plate, removing and installing: See DRIVE PLATE, REMOVING AND INSTALLING

6. 60 N.m (44 ft lb) plus additional 1/4 turn (90°) further

z

Always replace

7. Intermediate plate

z

Must be located on dowel sleeves

z

Do not damage/bend when assembling

8. Sealing flange with oil seal

z

Only replace as an assembly

z

Lightly oil sealing lip on oil seal

NOTE:

For clutch repairs: See CLUTCH ASSEMBLY

NOTE:

The following list refers to items in Fig. 40 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 40: Identifying Sealing Flange And Flywheel/Drive Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Sealing ring (crankshaft pulley side), replacing

Special tools and equipment

z

2080 A sleeve

z

3415 Counter support

z

3203 Seal remover

z

3265 Sleeve installer



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
