Fig. 35: Removing Engine Mount
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove vibration damper/belt pulley.

z

Remove toothed belt guard center and lower sections.

z

Mark engine direction of rotation on the toothed belt.

z

Remove toothed belt.

Toothed belts, installing

z

Make sure that TDC mark on flywheel and reference mark are aligned.

z

Loosen camshaft sprocket mounting bolt 1/2 turn.

z

Place a drift through hole in rear of toothed belt guard and release the camshaft sprocket from camshaft
taper with a light and careful hammer blow.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 36: Installing Drift Through Hole In Rear Of Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install toothed belts (note engine direction of rotation) on crankshaft toothed belt sprocket, intermediate
wheel, injection pump sprocket and tensioning roller.

z

Install camshaft sprocket together with toothed belt and position using mounting bolt.

z

Camshaft sprocket should still turn

z

Tension toothed belt; using pin wrench on eccentric, turn clockwise until notch and raised mark align
(arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 37: Tightening Lock Nut On Tensioning Roller
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten lock nut on tensioning roller.

z

Tightening torque: 20 N.m (15 ft lb)

NOTE:

Observe correct installation of tension roller in rear toothed belt guard
(arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 38: Identifying Correct Installation Of Tension Roller
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check TDC mark on flywheel again.

z

Tighten camshaft sprocket mounting bolt.

z

45 N.m (33 ft lb)

z

Tighten the new mounting bolts of injection pump sprocket

z

Tightening torque: 20 N.m (15 ft lb)

NOTE:

z

After dynamically checking the "start of injection", the mounting
bolts must be retightened 90° (1/4 turn).

See DIESEL INJECTION PUMP, REMOVING AND INSTALLIN



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
