Volkswagen New Beetle. Manual - part 1119





Toothed belts, removing, installing, tensioning

Special tools and equipment

z

2068 A Adj. gauge TDC tool

z

3359 Rig pin

z

3418 Adjustment guide

z

10-222A Engine support bridge with 10-222A/1 bracket for engine

z

V159 nut wrench

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

Fig. 26: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Support tool 10-222 A/21, modifications

NOTE:

z

Use tool 10-222A to support the engine / transmission assembly.

z

Drill a new hole in the 10-222 A/21 guide to fasten 10-222 A/8 adaptor to.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Toothed belts, removing

z

Remove tube between charge air cooler and Air intake pipe. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING


z

Disconnect fuel supply and return lines at fuel filter.

z

Remove fuel filter from bracket.

z

Remove toothed belt guard - upper section.

z

Remove valve cover.

z

Remove brake booster vacuum pump.

z

Remove pipe between charge air cooler and turbocharger. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING
 .

z

Remove insulation tray - right side

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

With engine installed:

z

Turn crankshaft to cylinder 1 TDC.

Fig. 27: Identifying New Hole On 10-222 A/21 Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Dimensions given are in mm.

z

One hole 12.5 mm diameter (arrow) drilled in the 10-222 A/21 guide

NOTE:

The valve cover has an integrated, vulcanized gasket. If damaged or
leaking replace the valve cover.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 28: Identifying Timing Mark (Manual Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft to cylinder 1 TDC.

Fig. 29: Identifying Timing Mark (Automatic Transmission)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

With engine removed:

Vehicles with manual transmission

z

Install adjustment device 2068 A as shown.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 30: Installing Adjustment Device On Flywheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Set adjustment device to 96 mm (arrow -A-). Left-hand notch of vernier scale is reference point.

z

Turn crankshaft until flywheel TDC marking aligns with point on setting device (arrow -B-).

Vehicles with automatic transmission

z

Install adjustment device 2068 A as shown.

Fig. 31: Installing Adjustment Device On Flywheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Set adjustment device to 96 mm (arrow -A-). Left-hand notch of vernier scale is reference point.

z

Turn crankshaft until flywheel TDC marking aligns with point of setting device (arrow -B-).

All vehicles

z

Lock camshaft using setting bar.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
