Volkswagen New Beetle. Manual - part 1118





2. 40 N.m (30 ft lb) plus additional 1/4 turn (90°)

z

Always replace

3. 15 N.m (11 ft lb)

4. 22 N.m (16 ft lb)

5. Toothed belt guard, lower section

6. 10 N.m (7 ft lb)

7. Toothed belt guard

8. 45 N.m (33 ft lb)

9. Right engine bracket

10. Toothed belt guard, upper section

11. Toothed belt

z

Mark engine direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING
 .

12. Idler wheel

13. 20 N.m (15 ft lb) plus additional 1/4 turn (90°)

z

Always replace

14. 20 N.m (15 ft lb)

15. 20 N.m (15 ft lb)

16. 45 N.m (33 ft lb)

17. Camshaft sprocket

z

Drive camshaft off of taper using hammer and drift through toothed belt guard openings

z

to loosen and tighten bolt (item 16), counterhold using 3036

18. Tensioning roller

z

Semi-automatic toothed belt tensioning roller, checking. See SEMI-AUTOMATIC TOOTHED
BELT TENSIONING ROLLER, CHECKING
 .

19. Idler wheel

20. Injection pump sprocket

z

Two piece construction

21. 30 N.m (22 ft lb)

22. Toothed belt guard, rear

23. Coolant pump

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING .

24. Idler wheel

z

First remove, to remove coolant pump

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



25. Crankshaft toothed belt sprocket

26. Bushing

27. Diesel injection pump

z

Removing and installing

See DIESEL INJECTION PUMP, SERVICING .

28. Assembly bracket

z

for Diesel injection pump, Generator and power steering pump.

z

for vehicles with A/C

z

Removing and installing

See 1.9L4-CYLINDER TDI ENGINE .

29. 45 N.m (33 ft lb)

Fig. 22: Identifying Front Engine Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Ribbed belt tensioner, removing and installing

Work sequence

z

Remove right-hand insulation tray:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Remove pipe between charge air cooler and turbocharger. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING
 .

z

Mark engine direction of rotation on ribbed belt.

z

Swing tensioning roller in direction of arrow using 15 mm open end wrench on tensioning lever.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 23: Removing Or Installing Ribbed Belt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove or install ribbed belt.

Ribbed belt, routing

Belt drive without A/C compressor

1. Vibration damper/pulley

2. Tensioner

3. Pulley - Generator

4. Ribbed belt

5. Pulley - Power steering pump

NOTE:

z

Vehicles without A/C: first remove V-belt from Generator and position
it last when installing.

z

Vehicles with A/C: first remove V-belt from pulley and position it last
when installing.

z

When installing V-belt; make sure belt sits correctly in pulley.

NOTE:

The following list refers to items in Fig. 24 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 24: View Of Belt And Pulleys
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Belt drive with A/C compressor

1. Vibration damper/pulley

2. Tensioner

3. Pulley - Generator

4. Pulley - Power steering pump

5. Tensioner

6. Ribbed belt

7. Pulley - A/C

Fig. 25: Identifying Belt Drive With A/C Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 25 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
