Volkswagen New Beetle. Manual - part 1120







2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 32: Installing Setting Bar On Camshaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Centralize setting bar as follows:

Turn camshaft so that one end of setting bar contacts the cylinder head. Using feeler gauge establish the
gap at the other end of the setting bar. Place a feeler gauge corresponding to half the gap between setting
bar and cylinder head. Turn camshaft until the setting bar contacts the feeler gauge. Place a 2nd feeler
gauge, of same thickness, at the other end between setting bar and cylinder head

z

Lock injection pump sprocket with pin.

z

Loosen injection pump sprocket mounting bolts -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 33: Locking Injection Pump Sprocket With Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Do NOT loosen hub nut -2-! Otherwise the Diesel injection pump basic
setting will be altered and cannot be reset with normal workshop
equipment.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Loosen tensioner.

z

Install 10-222A support with 10-222A/1 legs as shown.

Fig. 34: Installing 10-222A Support With 10-222A/1 Legs
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine mount -1- as follows:

z

Unscrew bolts (arrows)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
