z

VAG 1331 Torque wrench: 5 to 50 N (3.7 to 37 ft lb)

z

VAG 1332 Torque wrench: 40 to 200 N.m (30 to 148 ft lb)

Fig. 41: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove toothed belt. See TOOTHED BELTS, REMOVING, INSTALLING, TENSIONING .

z

Remove crankshaft toothed belt sprocket by counter-holding sprocket using 3415.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 42: Removing Crankshaft Toothed Belt Sprocket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To guide seal extractor, hand screw center bolt into crankshaft onto stop.

z

Unscrew inner part of oil seal extractor 3203 two turns (approx. 3 mm) out of outer part and lock with
knurled screw.

z

Lubricate threaded head of oil seal extractor, place it in position and while exerting firm pressure, screw it
in as far as possible into the oil seal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 43: Removing Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen knurled screw and turn inner part against crankshaft until the oil seal is pulled out.

Installing

z

Lightly oil sealing lip of oil seal.

z

Install guide sleeve from 2080 A onto crankshaft journal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 44: Installing Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press in sealing ring with press sleeve from 3265 up to the stop using center bolt -1-



2003 Volkswagen New Beetle GLS
