z

Check for distortion. See Fig. 68

z

Reworking sealing surface. See Fig. 102

z

Removing and installing. See CYLINDER HEAD, REMOVING AND INSTALLING

z

After replacement replace entire coolant amount

22. Oil deflector

23. Cylinder head cover gasket

z

Replace if damaged

z

Coat cylinder head/bearing cap transition points with D 454 300 A2 before installing

24. Cylinder head cover

z

With cable guide



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 67: Exploded View Of Cylinder Head Cylinder Head (Aluminum Cylinder Head Cover)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking Cylinder Head For Distortion



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 68: Checking Cylinder Head For Distortion
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Max. permissible distortion: 0.1 mm

Toothed belts, removing, installing and tensioning



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Adjusting valve timing.

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

10-222 A Support device (Modifying guide 10-222 A/21. See MODIFYING GUIDE 10-222 A/21
FROM SUPPORT DEVICE 10-222 A
 )

z

10-222 A/8 Adapter

z

V.A.G 1331 Torque wrench (5...50 N.m)

z

V.A.G 1332 Torque wrench (40...200 N.m)

z

T 10020 Two-hole pin wrench

Fig. 69: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Modifying guide 10-222 A/21 from support device 10-222 A



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
