z Internal dial gauge 50...100 mm z Measure bores at 3 locations in both directions -A- across engine and -B- in line with crankshaft. Deviation from nominal dimension: max. 0.08 mm Piston and cylinder dimensions PISTON AND CYLINDER DIMENSIONS SPECIFICATIONS ENGINE - CYLINDER HEAD, VALVETRAIN CYLINDER HEAD, REMOVING AND INSTALLING CYLINDER HEAD Checking compression. See Compression pressures, checking . Engines with steel cylinder head cover: z Engine code AEG. See ENGINES WITH STEEL CYLINDER HEAD COVER Engines with aluminum cylinder head cover. z Engine codes AVH, AZG, BDC, BEV, BGD. See ENGINES WITH ALUMINUM CYLINDER Engines with steel cylinder head cover Honing dimension Piston diameter Cylinder bore diameter Basic dimension 82.465 (1) 82.51 1st oversize 82.965 (1) 83.01 (1) Dimensions without graphite coating (thickness 0.02 mm). Graphite coating wears away NOTE: z When installing an exchange cylinder head with fitted camshaft, lubricate z The plastic packing pieces for protecting the open valves must not be z If the cylinder head is replaced, all the coolant in the system must also be z Removing and installing intake manifold. See INTAKE MANIFOLD UPPER
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
|
