Volkswagen New Beetle. Manual - part 1060





Fig. 62: Checking Ring To Groove Clearance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools, testers, measuring instruments and auxiliary items required

z

Feeler gauge

Work sequence

Clean groove before checking.

PISTON RING TO GROOVE CLEARANCE SPECIFICATIONS

Piston Ring

New

Wear limit

Compression rings
mm

0.06...0.09

0.20

Oil scraper ring

0.03...0.06

0.15



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Measuring Piston Lower Edge Of Skirt

Fig. 63: Measuring Piston Lower Edge Of Skirt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools, testers, measuring instruments and auxiliary items required

z

External micrometer 75...100 mm

Work sequence

z

Measure pistons approx. 10 mm from the lower edge of skirt, 90° offset to axis of floating piston pin.

Deviation from nominal dimension: max. 0.04 mm

mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Installation Position Of Bearing Shells

Fig. 64: Identifying Installation Position Of Connecting Rod Bearing Shells
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Bearing shell -1- with oil channel (arrow) for connecting rod

Bearing shell -2- without oil channel connecting rod bearing cap

z

Insert bearing shells and connecting rod bearing cap centrally.

Dimension -a- must be same on both left and right side, maximum deviation 0.2 mm

Checking Cylinder Bores



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 65: Checking Cylinder Bores
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools, testers, measuring instruments and auxiliary items required

NOTE:

Measuring the cylinder bores must not be done when the cylinder block is
mounted on a repair stand with adapter bracket VW 540, as incorrect
measurements would then be possible.
