Fig. 57: Locating Upper Crankshaft Bearing Identification Marks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

In the factory the upper bearing caps are allocated with the correct thickness for the cylinder block. Colored
marks are used to identify the thickness of the bearing shells. See CRANKSHAFT BEARING COLOR
MARKINGS .

Which thickness of shell should be installed to which location is marked by a letter on the lower sealing surface
of the cylinder block -x-.

Arrow indicates direction of travel (forward).

Crankshaft bearing color markings

CRANKSHAFT BEARING COLOR MARKINGS SPECIFICATIONS

Letter on cylinder block

Color of bearing

S =

Black

R =

Red



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Crankshaft dimensions

Dimensions in mm.

CRANKSHAFT DIMENSIONS SPECIFICATIONS

PISTON AND CONNECTING ROD, DISASSEMBLING AND ASSEMBLING

Gradual introduction of "industrially fractured" connecting rods.

G =

Yellow

NOTE:

z

If the colored marks have not been stamped or are no longer legible, use
the average bearing shell (red).

z

The lower crankshaft bearing shells are always supplied as a spare part
with the color marking "yellow".

Grinding dimension

(1)

Crankshaft bearing journal diameter

Connecting rod journal diameter

Basic dimension

-0.017

54.00

-0.037

-0.022

47.80

-0.042

1st undersize

-0.017

53.75

-0.037

-0.022

47.55

-0.042

2nd undersize

-0.017

53.50

-0.037

-0.022

47.30

-0.042

3rd undersize

-0.017

53.25

-0.037

-0.022

47.05

-0.042

(1)

All dimensions are in mm.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 58: Identifying "Industrially Fractured" Connecting Rods
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Distinguishing features:

A. Older type connecting rods (smooth joint along contact surface)

B. Industrially fractured connecting rods (rough joint along contact surface)

z

Disassembling and assembling piston and older type connecting rod. See OLDER TYPE
CONNECTING RODS

z

Disassembling and assembling piston and industrially fractured connecting rod. See INDUSTRIALLY
FRACTURED CONNECTING RODS

Older type connecting rods



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



1. Piston rings

z

Offset gaps by 120°

z

Use piston ring pliers to remove and install

z

"TOP" faces piston crown

z

Checking ring gap. See Fig. 61

z

2-part oil scraper ring

2. Piston

z

Checking. See Fig. 63

z

Mark installation position and cylinder number

z

Arrow on piston crown points to belt pulley end

z

Checking ring to groove clearance. See Fig. 62

z

Install using piston ring clamp

3. Connecting rod

z

Only replace as a set

z

Mark allocation to cylinder -B-

z

Installation position: Marking -A- faces belt pulley end

4. Connecting rod bearing cap

z

Mark allocation to cylinder -B-

z

Installation position: Marking -A- faces belt pulley end

5. 30 N.m + 1/4 turn (90°) further

z

Replace

z

Oil thread and contact surface

z

To measure radial clearance tighten to 30 N.m, but do not turn further

6. Bearing shell

z

Observe installing position

z

Do not interchange used bearing shells

z

Ensure retaining lugs fit tightly in recesses

z

Upper bearing shell with oil drilling for piston pin lubrication

z

Axial clearance, new: 0.05 ... 0.31 mm; Wear limit: 0.37 mm

z

Check radial clearance with Plastigage, new: 0.01 ... 0.06 mm; Wear limit: 0.12 mm

z

Do not rotate crankshaft when checking radial clearance

7. Cylinder block

z

Checking cylinder bore. See Fig. 65

z

Piston and cylinder dimensions. See PISTON AND CYLINDER DIMENSIONS

8. Connecting rod bolt

NOTE:

The following list refers to items in Fig. 59 .
